Working voltage: DC24V Max power: 13W
Beam angle: 120/270/330 IP grade : IP66
LED quantity: 5050RGB LED type: 32PCS
Pixel : 32PCS Grey scale: 65536
Channel: RGB Weight: 0.32KG
Size of 3 kinds of diffuser:
Size of 3 kinds of diffuser:
65536 gray levels , Frequency can be 18KHz, high refresh rate without flicker;
External IC, higher power, high light transmittance PC cover, higher brightness;
Beam angle of different diffuser
Comparison of Pixel Bar and Pixel Bar Pro Data
Beam angle of different diffuser
Comparison of Pixel Bar and Pixel Bar Pro Data
IC Power Cascade Grey IP Flat Clear Round Milky
Length Scale Grade Cover Illumination Cover Illumination
Length Scale Grade Cover Illumination Cover Illumination
CL05 13.5W 10M 256 IP65 259Lx 104Lx
CL28HL 16.9W 10M 65536 IP66 478Lx 192Lx
CL28HM 19.5W 8M 65536 IP66 568Lx 235Lx
CL28HH 25.6W 6M 65536 IP66 658Lx 276Lx
Note: The test condition is that the distance between the controller to the first led bar is 15m
CL28HL 16.9W 10M 65536 IP66 478Lx 192Lx
CL28HM 19.5W 8M 65536 IP66 568Lx 235Lx
CL28HH 25.6W 6M 65536 IP66 658Lx 276Lx
Note: The test condition is that the distance between the controller to the first led bar is 15m
Can connect the led tube together without gap; Simple and convenient installation;
Easy to build setup
Clamp installation
It can be installed and fixed on the truss with clamp, and its angle can be adjusted arbitrarily.
Connect the led bar with controller
Clamp installation
It can be installed and fixed on the truss with clamp, and its angle can be adjusted arbitrarily.
Connect the led bar with controller
The XLR cable connects with the output port of the controller and the input cable of the led bar
(male connector is input, and female connector is output).
Waterproof connector cable, rotating buckle can be locked to prevent accidental fall off；
Connect the controller with software
Connect the signal input port of the controller via network cable
Connect the controller with console
Connect the console and the controller through the signal conversion board.
Flight Case Packaging
Waterproof connector cable, rotating buckle can be locked to prevent accidental fall off；
Connect the controller with software
Connect the signal input port of the controller via network cable
Connect the controller with console
Connect the console and the controller through the signal conversion board.
Flight Case Packaging
